Pixfra™ Arc LRF A650 Pro Thermal Monocular w/Laser Rangefinder (640x512 12µm Detector/50mm Lens)

SKU#PIX-PFI-A650P-LRF Pixfra

Pixfra™ Arc LRF A650 Pro Thermal Monocular w/Laser Rangefinder (640x512 12µm Detector/50mm Lens)

1 in stock

High-resolution 640×512, 12µm thermal sensor with <20mK NETD for exceptional image detail.
50mm f1.0 lens with 15.4 × 12.3m field of view @ 100m and detection range of up to 2600m.
Integrated laser rangefinder with 1000m range and ±1m accuracy for precise distance data.
Durable magnesium alloy housing with IP67 weatherproof protection.
Up to 6 hours runtime with replaceable 18650 batteries and USB-C charging.
Pixfra Outdoor app compatibility for real-time wireless sharing with up to four users.

VIEW PRODUCT INFO / SPECS

Select Model: A650 - 50mm, 640x512

Whilst we aim to dispatch in-stock items within 1 working day, please be aware that during busy periods dispatch of in-stock items may be delayed by up to 2 working days. Authorised UK Retailer

WHY BUY FROM US?

PRICE MATCH

SWAP-OUT GUARANTEE

FAST DELIVERY

30 DAY RETURNS

UNMATCHED SERVICE

OBSIDIAN REWARDS

Founded in Devon in 2007, Optics Warehouse has grown to become the UK’s largest specialist optics retailer, offering an unrivalled selection of rifle scopes, thermal imagers, night vision, binoculars, red dots, mounting systems and shooting accessories from the world’s leading brands, all backed by competitive pricing, expert advice and outstanding customer service.

Shaun Ellis, Managing Director Long range target shooting and deer stalking.

Product Information FIND OUT MORE

DESCRIPTION

The Pixfra™ Arc LRF A650 Pro Thermal Monocular combines outstanding long-range thermal performance with precise distance measurement, delivering unmatched clarity and accuracy in the field. Equipped with a highly sensitive 640×512, 12µm <20mK NETD thermal sensor and a fast 50mm f1.0 lens, the A650 Pro achieves a wide 15.4 × 12.3m field of view at 100m and an extended detection range of up to 2600m. Its seamlessly integrated laser rangefinder provides accurate measurements up to 1000m with ±1m precision, allowing for confident, informed decisions during observation. Built in a rugged magnesium alloy housing with IP67 protection, this device is lightweight, ergonomic, and ready for any environment. With extended battery life, intuitive controls, and wireless app connectivity, the A650 Pro is an indispensable companion for wildlife observation, hunting, and professional fieldwork.

Click here to download the app for Android devices.

Click here to download the app for iOS devices.

SPECS

Detector Type Vanadium oxide uncooled focal plane detector
Thermal Sensor 640×512, 12µm, <20mK NETD
Frame Rate 50 Hz
Lens 50mm f1.0
FOV (m @ 100 m) 15.4 × 12.3
Thermal Focus Control Manual
Close Focus Distance 2 m (6.56 ft)
Rangefinder Built-in precision laser rangefinder
Distance Measurement Range 1000 m
Digital Zoom 1x, 2x, 4x, 8x
Magnification 3.37x
Colour Palettes 6 (white hot, black hot, iron red, alarm, amber, emerald)
Display 0.41″ 1440×1080 OLED
Storage 32 GB
Uniformity Correction Auto, manual
Picture in Picture (PiP) Yes
Audio Recording Yes
Hot Spot Trace Yes
Wi-Fi Yes
Power Supply 5 VDC/1 A, USB Type-C
Battery Type 1 replaceable 18650 battery
Battery Capacity 3,200 mAh
Battery Operating Life Up to 6 hours (depending on temperature)
Environmental Protection IP67
Product Dimensions 186 × 59 × 82 mm / 7.32″ × 2.32″ × 3.23″ (L × W × H)
Packaging Dimensions 228 × 120 × 187 mm / 8.98″ × 4.72″ × 7.36″ (L × W × H)
Weight 430 g

FEATURES

Long-range Thermal Capability: The 50mm f1.0 lens and sensitive 640×512 thermal sensor offer superior clarity with a detection range of up to 2600m.
Enhanced Image Processing: Pixfra’s PIPS 2.0 ensures sharp, noise-reduced, and contrast-rich thermal imagery in all conditions.
Precision Laser Rangefinder: Seamlessly integrated LRF provides reliable measurements up to 1000m with ±1m accuracy.
Ergonomic Comfort: Contoured eyecup and textured rubber grip offer secure handling during prolonged observation sessions.
Rugged Lightweight Build: Compact magnesium alloy body is impact-resistant, lightweight, and built to withstand demanding fieldwork.
All-weather Reliability: IP67 certification ensures resistance to rain, snow, fog, and high humidity.
Uninterrupted Power: Powered by replaceable 18650 batteries for up to 6 hours operation, with secure twist-cap design and USB-C charging.
Wireless Sharing & Recording: Wi-Fi connection with Pixfra Outdoor app allows live sharing with up to four viewers, plus Picture-in-Picture, audio recording, and hot spot tracking.
Custom Viewing Experience: Six colour palettes, digital zoom up to 8×, and uniformity correction options allow users to adapt the display to varying conditions.

WHAT'S IN THE BOX

Pixfra™ Arc LRF A650 Pro Thermal Monocular w/Laser Rangefinder (640x512 12µm Detector/50mm Lens)

FREQUENTLY ASKED QUESTION(S)

What is the maximum detection and laser rangefinder distance for the Arc LRF A650 Pro?

The monocular features a powerful 50mm f/1.0 objective lens and a high-sensitivity 640x512 thermal sensor, allowing you to detect heat signatures at an extended range of up to 2,600 meters. Additionally, its seamlessly integrated, precision Laser Rangefinder (LRF) can measure distances up to 1,000 meters with an accuracy of ±1 meter.

How long does the battery last, and can it be replaced in the field?

Yes, the device is built for extended observation sessions. It is powered by a replaceable 18650 rechargeable Li-ion battery, which provides up to 6 to 7 hours of continuous operation (depending on temperature and usage of Wi-Fi/LRF). The package includes two 18650 batteries and a dual charger, allowing you to quickly swap out the battery in the field via the secure twist-cap battery cover for up to 14 hours of total combined runtime.

Can I stream or share the live thermal view with other people?

Yes. The Arc LRF A650 Pro is equipped with built in WiFi hotspots and is fully compatible with the Pixfra Outdoor app. It allows up to four smart devices (such as phones or tablets) to connect simultaneously within a 20 meter range. This feature enables group viewing and real time observation sharing without needing to hand over the physical device.

How well does this thermal monocular perform in harsh weather conditions?

The device is built with a rugged, lightweight magnesium alloy body and carries an IP67 weatherproof rating. This means it is fully protected against dust ingress and can withstand heavy rain, dense fog, snow, high humidity, and even temporary submersion in water. It operates efficiently in extreme temperatures ranging from -30°C to +55°C.

Does the device record audio along with video, and how much internal storage does it have?

Yes, unlike many standard thermal monoculars, the Arc LRF A650 Pro supports video recording with audio, as well as snapshot captures. It features 32 GB of built-in EMMC internal storage, providing plenty of space to save your field footage and spatial data before transferring it to your phone or computer via a USB-C cable.
