Optisan Optics EVX G2 4-16x44 F1 FFP Non Illuminated MRAD16 Side Focus 0.1 MRAD LT Rifle Scope
- 30m tube
- Locking turrets
- First focal plane MRAD based reticle
- MRAD16 reticle
- Non Illuminated
- 3 inch sunshade included
- Zoom lever included
- Versatile 4-16x magnification range
Optisan Optics EVX G2 4-16x44 F1 Non Illuminated MRAD16 Side Focus 0.1 MRAD LT Rifle Scope
Brand new to the Optisan range of optics is highly anticipated Optisan EVX G2 4-16x44 FFP , this eagerly awaited replacement for the discontinued EVX G1 has finally arrived. The Optisan EVX G2 4-16x44 F1 comes with a first focal plane milradian based non illuminated MRAD16 reticle. This simple yet effective reticle features a series of hash marks from the center cross from 1 MRAD to 15 MRAD quick hold over 0.1 and 0.05 MRAD mil-dots that offer quick hold points for windage calls and windage hold offs. These dots start from the 1 MRAD has mark and move out across the windage in 1 MIL increments in a XMAS tree fashion until reaching the 5 MRAD hash marking on the elevation.
The Optisan EVX G2 4-16x44 F1 has a 30mm tube that provides 20.4 MRAD of internal adjustment and 0.1 MRAD turrets which are lockable ensuring the user cannot accidententally knock these in the field or while transporting their firearm. The Optisan EVX G2 4-16x44 FFP has an improved optical system which helps provide the shooter with better optical clarity and resolution. This versatile rifle scope is perfect for air rifle shooters and centerfire shooters; its an ideal choice for a HFT shooter but also a great choice for a shooter looking to come in at a budget in the rimfire PRL league.
| OPTICAL DATA | |
|---|---|
| Magnification (High) | 16X |
| Magnification (Low) | 4X |
| Objective Diameter (mm) | 44mm |
| Outer dia. Objective (mm) | 52mm |
| FOV (min.mag）(ft/100yds) | 27.2 |
| FOV (max.mag）(ft/100yds) | 6.5 |
| Eye relief (in) | 3.8'' - 3.5'' |
| Exit Pupil (Max mag.） (mm) | 2.75mm |
| Exit Pupil (min. mag.） (mm) | 11mm |
| Diopter Range (dpt) | +/- 2.0 |
| Parallax Adjustment | 10yds - infinity (100 yds pa free) |
| Coating | Fully multi-coated |
| MECHANICAL DATA | |
| Tube Construction | One-piece tube, aircraft aluminum |
| Elevation Adjustment (value per click) | 0.1 mrad |
| Windage Adjustment (value per click) | 0.1 mrad |
| Turret Style (Elevation) | Lockable Target Turret |
| Turret Style (Windage) | Lockable Target Turret |
| Travel Per Rotation | 10 MRAD |
| Elevation adj. range | ≥ 20.40 mrad |
| Windage adj. range | ≥ 14 mrad |
| Eye Piece Diameter (in) | 1.73'' |
| Eye Piece Diameter (mm) | 44mm |
| Eye Piece Length (in) | 2.15'' |
| Eye Piece Length (mm) | 51.2mm |
| Mounting Length rear (mm) | 56.5mm |
| Mounting Length front (mm) | 58.5mm |
| Tube Dia. (mm) | 30mm |
| Length (in) | 13.81'' |
| Length (mm) | 351mm |
| Weight (g) | 748g |
| Weight (oz) | 26.38oz |
| Surface Finish | Matte Black |
| ENVIRONMENT DATA | |
| Functional temperature | -20 ~ 50 degree celcius |
| Storage temperature | -20 ~ 50 degree celcius |
| Submersion tightness | JIS 7 |
| RETICLE DATA | |
| Reticle | F1MRAD16 |
| Calibrated Ranging Power | Not applicable |
| Focal plane | First |
| Illumination | Non-illuminated |
| DELIVERY INCLUDE | |
| Standard Accessories | Lens covers, blank elevation turret dial, 3'' sunshade, speed lever. |
- 30m tube
- Locking turrets
- First focal plane MRAD based reticle
- MRAD16 reticle
- Non Illuminated
- 3 inch sunshade included
- Zoom lever included
- Versatile 4-16x magnification range
The F1MRAD16 reticle is an all-round MRAD(MIL) based reticle designed for precision ranging at all magnifications with uncluttered view and fine windage correction reference marks.
The graphic shows how the reticle looks at 8x, subtensions remain constant at all magnifications. On the upright corner is the blow-up graphic of the center of the reticle. The overall reticle image will vary with changes in the magnification.
- Optisan EVX G2 4-16x44 F1
- Lens covers
- Blank elevation turret dial
- 3'' sunshade
- Speed lever
10 Year Warranty
