WIN A: Pixfra MILE 2 M207 Handheld Thermal Monocular - 256x192/12µm/7mm 35mk
The M207 showcases its vivid thermal imagery on a 0.32-inch AMOLED display, offering a 90% DCI-P3 color gamut for lifelike detail and vibrant color accuracy, even in low-light conditions. Whether used for tracking wildlife or monitoring landscapes, the display presents anatomical and environmental details with stunning clarity. Designed with a sleek and slim profile, the device incorporates the power button into the Pixfra logo on the side, reducing the need for additional buttons and allowing for streamlined operation. Weighing only 270 grams, the Mile 2 M207 is highly portable and can be effortlessly carried in a pocket or pack, making it convenient for extended use or quick access on the go.
Built for durability, the Mile 2 M207 is rated IP67, offering robust protection against dust and water, so it can withstand harsh weather conditions such as heavy rain and high humidity. Its dependable performance is maintained across a wide temperature range, from -30°C to 55°C, ensuring reliable use in extreme environments. Additionally, the device's long-lasting rechargeable lithium battery delivers up to 9.5 hours of continuous use, making it ideal for long outings, whether day or night.
With integrated Wi-Fi connectivity, the M207 pairs seamlessly with the Pixfra app on Android and iOS, allowing users to view thermal imaging in real-time on their smartphones or tablets within a 40-meter range. This connectivity supports simultaneous pairing with up to four devices, facilitating collaborative observations for teams or groups. Built-in video recording, still image capture, and 16GB of storage allow users to document their findings directly on the device, with versatile color palette options like white-hot, black-hot, and iron red for added image customization.
The Pixfra Mile 2 M207 comes with a range of practical accessories, including a USB Type-C charging cable, wristband, lanyard, lens cloth, camera pouch, eyeshade, quick start guide, and a three-year warranty. With its balance of advanced thermal technology, rugged design, and user-friendly features, the M207 is an ideal choice for those who require a reliable and portable thermal monocular that performs in any environment.
Product Name A-Z | WIN A: Pixfra MILE 2 M207 Handheld Thermal Monocular - 256x192/12µm/7mm 35mk |
---|---|
SKU | OPTICSDRAWS#976 |
Specs
- Thermal Sensor: 256×192, 12μm, <35mK NETD
- Objective Lens: 7mm f1.0
- Spectral Range: 8 μm–14 μm
- Field of View: Horizontal: 24.0°, Vertical: 18.0° (H: 43.9 m, V: 32.9 m at 100 m)
- Focus Control: Fixed-focal
- Close Focus Distance: 1 m (3.28 ft)
- Detection Range: Up to 350 m
- Magnification: 1.1x
- Frame Rate: 50 Hz
- Display: 800 × 600, 0.32-inch OLED
- Color Palettes: 6 (white hot, black hot, iron red, alarm, emerald, amber)
- Video Compression: H.264
- Diopter: –3 D to +1 D
- Eye Relief: 13 mm (0.51 inch)
- Exit Pupil: 5 mm (0.20 inch)
- Digital Zoom: 1×, 2×, 4×, 8×
- Video Recording: Yes
- Still Image Capture: Yes
- Wi-Fi Hotspot: Yes
- Hot Spot Tracking: Yes
- Video Distance Measurement: Yes
- FFC Calibration: Auto, Manual, External Correction
- Standby Mode: Yes
- DPC (Defective Pixel Correction): Yes
- Storage: Built-in 16GB
- Battery Type: Rechargeable Lithium Battery
- Battery Life: 9.5 hours (at 25°C)
- Power Supply: 5 VDC/2 A
- Port: USB Type-C
- Overvoltage Protection: Yes
- Operating Temperature: –30 °C to +55 °C (–22 °F to +131 °F)
- Operating Humidity: ≤95%
- Protection Grade: IP67
- Product Dimensions: 149.0 mm × 56.6 mm × 50.3 mm (5.87″ × 2.23″ × 1.98″) (L × W × H)
- Gross Weight: 760 g (1.68 lb)
- Net Weight: 270 g (0.60 lb)
Features
-
High-Sensitivity Thermal Sensor: Equipped with a 256×192, 12μm thermal sensor with <35mK NETD sensitivity, detecting subtle temperature differences for precise imaging.
-
Long Detection Range: Capable of detecting heat signatures up to 350 meters, ideal for wildlife observation, search and rescue, and outdoor activities.
-
Wide Field of View (FOV): 24.0° field of view from a 7mm f1.0 objective lens, allowing broad area scanning with reduced need for repositioning.
-
Vivid AMOLED Display: Features a 0.32-inch AMOLED screen with a 90% DCI-P3 color gamut for clear, detailed, and vibrant thermal images.
-
Digital Zoom Options: Offers 1×, 2×, 4×, and 8× digital zoom, enhancing viewing precision and image clarity for distant objects.
-
Seamless Wi-Fi Connectivity: Connects to the Pixfra app on Android and iOS devices, supporting live viewing on up to four smart devices within a 40-meter range for group observation.
-
Durable IP67-Rated Design: Dustproof and water-resistant, able to operate in adverse weather conditions, including high humidity and temperatures from –30°C to +55°C.
-
Compact and Lightweight: Slim design with an integrated power button, weighs only 270g, making it comfortable to hold, easy to carry, and highly portable.
-
Long Battery Life: Rechargeable lithium battery provides up to 9.5 hours of continuous use, suitable for extended outdoor sessions.
-
Built-In Video and Image Capture: Includes video recording and still image capture capabilities with built-in 16GB storage, enabling documentation and sharing of observations.
-
Multiple Color Palettes: Offers six color modes (white-hot, black-hot, iron red, alarm, emerald, and amber) to suit various observation needs and preferences.
-
Advanced Calibration and Correction: Features FFC (Flat Field Correction) calibration (auto, manual, and external) and DPC (Defective Pixel Correction) for improved image accuracy.
-
Additional Measurement Tools: Hot spot tracking and video distance measurement functions add precision for specific applications.
-
User-Friendly Accessories: Comes with a USB Type-C charging cable, wristband, lanyard, lens cloth, camera pouch, eyeshade, quick start guide, and a three-year warranty for added convenience and support.
In the box?
- Pixfra MILE 2 M207 Handheld Thermal Monocular - 256x192/12µm/7mm 35mk
- USB Type-C Charging Cable
- Wristband
- Lanyard
- Lens Cloth
- Camera Pouch
- Eyeshade
- Quick Start Guide
Warranty
- Pixfra 3 year warranty
