Optical Data
- Magnification (High/Low): 10x
- Objective Diameter: 32mm
- Outer Diameter Objective: 40mm
- Field of View (FOV) (min/max): 10.80 ft/100 yds
- Eye Relief: 3.24 inches
- Exit Pupil (Max/Min): 3.2 mm
- Diopter Range: +/- 2.0 dpt
- Parallax Adjustment: 10 yds to infinity (100 yds parallax-free)
- Coating: Fully Multi-coated
Mechanical Data
- Tube Construction: One-piece tube, aircraft aluminum
- Elevation Adjustment (Value per Click): 0.1 mrad
- Windage Adjustment (Value per Click): 0.1 mrad
- Turret Style (Elevation): Low-profile, Zero-resettable
- Turret Style (Windage): Low-profile, Zero-resettable
- Travel per Rotation: 10 mrad
- Elevation Adjustment Range: ≥ 20 mrad
- Windage Adjustment Range: ≥ 20 mrad
- Eyepiece Diameter: 1.55 inches / 39.5 mm
- Eyepiece Length: 1.65 inches / 42 mm
- Mounting Length (Rear): 55.50 mm
- Mounting Length (Front): 37.50 mm
- Tube Diameter: 30 mm
- Length: 9.52 inches / 242 mm
- Weight: 478 g / 16.86 oz
- Surface Finish: Matte Black
Environment Data
- Functional Temperature: -20°C to 50°C
- Storage Temperature: -20°C to 50°C
- Submersion Tightness: JIS 7
Reticle Data
- Reticle: SFP MH10X
- Calibrated Ranging Power: 10x
- Focal Plane: Second
- Illumination: Non-illuminated
