Specs

Electronic components

• Type of sensor: CMOS sensor
• Sensor resolution, pixels: 4K (3840x2160)
• Display type: FLCOS
• Display Resolution, pix.: 1280x720
• Built-In Video Recorder Availability: Yes
• Maximum memory card supported, Gb: 256
• Format of video clip: AVI
• Resolution of video clip: 1080/4k
• Format of photo files: JPEG
• Resolution of photo files: 4k
• Memory capacity: Approximately 1.75 hours video with 64gb SD card on 4k@30
  quality level.

Optical characteristics

• Magnification: 4 - 32
• Lens diameter, mm: 40
• Digital zoom: 1-8x
• Field of View,°, horizontal: 4
• Field of View, m@100m: 7
• Field of View, ft@100yd: 21
• Minimum focusing distance, ft/m: 12 / 3.6
• Eye Relief, in/mm: 2.4 / 60
• Diopter adjustment, dptr.: -6 to +3

IR-illuminator

• Emitter: LED
• IR Wavelengtt, nm: 850nm
• Equivalent IR Power, mW: ~1060 on high, ~540 on medium, ~400 on low
• Battery Life: 2 hours on high
• Battery type: 2x CR123A

Range of Detection

• Night Vision detection range, yd/m 300 / 274

Power Supply

• Power Supply, v: 6
• Battery type: 4xAA
• Battery life: 3.5Hrs Video Mode/ 4.5Hrs Preview Mode
• External Power Supply: 5V via microUSB

Reticle

• Windage & Elevation click value: 1/4 MOA
• Adjustment range, elevation: 92 MOA
• Adjustment range, windage: 215 MOA
• Number of reticle options: 10
• Colors: Black, white, red, blue, green, cyan, orange, yellow, magenta

Physical & operational characteristics

• Body Material: Aluminum
• Accessory rail mount: Picatinny
• Operating Temp,°F / C°: 20 to 122 / - 6 to + 50
• Waterproof rating: IP55 - water resistant
• Nitrogen Purged, yes/no: no
• Shockproof, yes/no: yes, 3ft
• Maximum recoil, caliber: .308
• Tube diameter: n/a
• Length, in/mm: 10.5 / 266
• Width, in/mm: 1.875 / 63
• Height, in/mm: 3 / 75
• Weight (with batteries), oz: 37.6
