Holosun IRIS-RD-44 Function Red & IR Laser & IR Illuminator & Whitelight
- Quad-function system combining red laser, IR laser, IR illuminator and 1,000-lumen white light
- Redesigned housing: 43% lighter, 29% lower and 28% narrower than the LS420
- Co-aligned red and IR lasers for simultaneous zeroing and consistent point-of-aim
- 60 mW VCSEL IR illuminator with on-the-fly beam divergence control
- Dual fire buttons plus Crane-plug remote for flexible, ambidextrous operation
- Powered by two CR123A batteries or one 18650 cell for maximum adaptability
Finance Calculator
Representative Calculation
Powered by Autify Digital Ltd
#1190
#1209
#1254
#1257
#1252
The Holosun IRIS-RD4 is a compact, high-performance quad-function aiming and illumination system designed for professionals and demanding shooters who require adaptability across both daylight and night-vision environments. Precision-machined from rugged 7075-T6 aluminium, the redesigned chassis is 43% lighter, 29% lower and 28% narrower than the legacy LS420. The result is a slimmer, lighter, and more ergonomic unit suited perfectly to PDWs, SBRs and full-length rifles.
At the core of the IRIS-RD4 is the integration of a co-aligned visible red laser, IR aiming laser, a powerful 60 mW VCSEL IR illuminator, and a 1,000-lumen white light generating 25,000 candela. This provides seamless transitions between daylight red-laser aiming, night-vision IR engagements, and high-intensity white-light illumination. With both lasers co-aligned, users can zero the visible laser in daylight and automatically align the IR laser to the same point-of-aim for instant consistency across all lighting conditions.
A top-mounted IR beam divergence slider allows rapid shaping of the IR illuminator from wide flood to narrow spot, optimising visibility for close-in search or long-range use. Dual independent fire buttons offer tactile, ambidextrous control of laser and white-light functions, supported by a refined rear power and mode selector. The included Crane-plug three-button remote provides even greater flexibility, including a visible-laser override.
Compatible with either two CR123A batteries (included) or a single rechargeable 18650 cell (not included), the IRIS-RD4 ensures reliable, high-output operation in all environments.
- Power Source Battery
- Battery Type CR123A / 18650
- Battery Life (Hours) Up to modes
- Thermal Modes N/A
- Digital Modes N/A
- Video Recording N/A
- Screen Refresh Rate N/A
- Digital Screen N/A
- Brightness Setting Up to modes
- Window Size (in) N/A
- Dimensions (in) 4.2 × 2.3 × 1.4
- Weight (oz) 8.5
- Housing Material 7075-T6 Aluminium
- Surface Finish Hard Anodise
- Adjustment per Click 0.5 MOA
- W&E Travel Range ±50 MOA
- Storage Temperature -40°C to 70°C
- Working Temperature -30°C to 60°C
- Submersion IPX8
- Vibration 1000G
- White LED Candela 25,000
- Laser & Illuminator Type Dual Laser & Dual Illuminator
- White LED Output 1,000 Lumens
- IR Illuminator Class Class 1
- IR Illuminator Output VCSEL 60 mW
- IR Pointer Class Class 1
- IR Pointer Output <0.7 mW
- Visible Laser Class 3R
- Visible Laser Output <5 mW
- Quad-mode aiming and illumination gives users full capability for daylight, night-vision and low-light scenarios in one streamlined unit.
- Visible red laser and IR laser co-alignment simplifies zeroing, allowing daylight adjustments to synchronise both lasers.
- VCSEL-based IR illuminator offers superior beam uniformity, improving visibility through night-vision optics.
- Top-mounted IR divergence slider allows instant beam shaping from wide flood to focused spot for different engagement distances.
- High-output white light provides strong target identification and situational awareness in indoor or outdoor conditions.
- Dual independent activation buttons offer natural tactile control, ideal for gloved operation or dynamic shooting environments.
- Three-button remote control offers additional activation points and a visible-laser override for immediate daylight use.
- Low-profile, lightweight housing improves balance when mounted to compact rifles and short-barrelled platforms.
- Durable hard-anodised aluminium body ensures operational reliability in harsh conditions.
- Flexible battery compatibility supports CR123A or 18650 power sources depending on user preference.
- Holosun IRIS-RD-4 Red & IR Laser & IR Illuminator & Whitelight
- HOLOSUN Limited Lifetime Warranty
