Exploring the Hikmicro Gryphon and Condor: A Detailed Comparison
When it comes to thermal imaging devices, two names that stand out are the Hikmicro Gryphon and Condor. These cutting-edge devices promise to take your thermal imaging experience to the next level. Let's delve into the specifics and highlight the differences between these two contenders.
Built to Last
In the realm of construction, the Condor boasts a newly designed magnesium alloy body, offering a lightweight yet durable frame at 450g, with improved ergonomics. On the other hand, the Gryphon utilises ABS plastic, tipping the scales at a heavier 546g.
The Eyes: Thermal Sensitivity
Both devices come equipped with thermal cameras, ensuring you get a comprehensive view of your surroundings at every time of the day. When it comes to sensitivity, the Condor again excels with a <20 mK rating compared to the Gryphon's <35 mK. Essentially, this measures the minimum temperature difference an infrared camera can detect, or Noise Equivalent Temperature Difference (NETD). As the Condor is able to detect lower heats, it will provide you with a richer image.
Image Enhancement Modes
Here's where the Condor takes a step ahead. With the Image Pro Mode and Zoom Pro Mode, users can expect enhanced clarity and focus. Unfortunately, the Gryphon lacks these specific modes, and once you start using them you’ll never want to go back!
Long-Range Capability
For those who need an extended reach, the Condor offers a 1000m Laser Range Finder (LRF), surpassing the Gryphon's 600m. If long-range detection is a critical requirement, the Condor will be your preferred choice.
The Lens Factor
Both devices share a 50mm F1.0 lens, but the Condor edges ahead with a magnification range of 3.0 - 24.0 (8x), allowing for more versatile zoom options compared to Gryphon's fixed 2.9x magnification.
Battery Life and Display
Both devices offer a 4.5-hour continuous running time from their lithium ion batteries, however the Condor comes with 3 rechargeable batteries, instead of the Gryphon’s two, allowing for over 13.5 hours of non-stop use. You’ll find a 1024 x 768 px, 0.39” OLED display on both models, ensuring a crisp and detailed view.
Additional Features
The Condor surprises with a magnetic lens cover, a small but practical addition that Gryphon’s lack. The Condor also boasts a speedy 3s boot-up time and a customisable user interface.
Making the Decision
In the end, the choice between the Hikmicro Gryphon and Condor boils down to your specific needs and preferences. The Gryphon, with its competitive price and reliable features, might suit those on a budget. On the other hand, the Condor, with its magnesium alloy build, advanced modes, and longer-range capabilities, is the go-to option for those seeking a premium thermal imaging experience.
If you think it’s time to make the upgrade, we could offer you up to £1200 for your Gryphon.
Get in touch with a member of our team to find out more.
Phone: 01803 3611895
Email: sales@opticswarehouse.co.uk
To view the whole Hikmicro Condor range click here >
For more info:
HIKMICRO Condor Pro CQ35L 35mm LRF 640x512 12µm <20mK Thermal Monocular
HIKMICRO Condor CH25L 25mm LRF 384x288 12µm <20mK Thermal Monocular
HIKMICRO Condor CH35L 35mm LRF 384x288 12µm <20mK Thermal Monocular
HIKMICRO Condor CQ50L Pro 50mm LRF 640x512 12µm <20mK Thermal Monocular
Gryphon GQ50L 50mm Pro VS Condor CQ50L 50mm Pro LRF Specification Table
|
Gryphon |
Condor |
|
|
Price |
£2199.99 |
£2,499.99 |
|
Body |
ABS plastic |
Magnesium alloy |
|
Weight (without battery) |
546g |
450g |
|
IP Rated |
IP67 |
IP67 |
|
Optical camera |
Yes |
No |
|
Thermal |
Yes |
Yes |
|
Image Pro Mode |
No |
Yes |
|
Zoom Pro Mode |
No |
Yes |
|
LRF |
600m |
1000m |
|
Focus Mode |
Manual |
Focus Ring |
|
Sensor |
640x512px |
640x512px |
|
Pixel Interval |
12μm |
12μm |
|
Sensitivity NETD |
< 35 mK |
< 20 mK |
|
Frame Rate |
50Hx |
50Hz |
|
Detection Range |
2600m |
2600m |
|
Lens |
50mm F1.0 |
50mm F1.0 |
|
Magnification |
2.9x |
3.0 - 24.0 (8x) |
|
InfraRed |
Optional attachment |
No |
|
Batteries |
2x rechargeable + charger |
3x rechargeable + charger - |
|
Battery life |
4.5-hour continuous running with CVBS, and hotspot function off (@25°C) |
4.5-hour continuous running with CVBS and hotspot function off (@25°C) |
|
Display Resolution |
1024 x 768 px, 0.39”, OLED |
1024 x 768 px, 0.39”, OLED |
|
Colour Palettes |
White Hot, Black Hot, Red Hot, Fusion, Visible |
White Hot, Black Hot, Red Hot, Fusion, Visible |
|
Magnetic Lens Cover |
No |
Yes |
|
Boot Up Time |
7s |
3s |
|
Customisable User Interface |
Yes |
Yes |
|
Operating Temperatures |
-30°C ~ +55°C |
-30°C ~ +55°C |
|
Audio and Video Available |
Video yes/Audio No |
Yes |
