Schmidt & Bender PM II ShortDot Dual CC 1-8x24 Illuminated MDR 1cm cw ST MTC LT / ST ZC LT Rifle Scope
#427
#424
#428
#425
#426
The Schmidt & Bender PM II ShortDot Dual CC 1-8x24 is one of the most technically advanced riflescope on the planet. Unique to the Schmidt and Bender 1-8x24 PM II ShortDot Dual CC is its a 8x magnification range that is mixed with a distinct illuminated red center red dot that is based in the second focal plane that can be used for close target work and the first focal plane hold off tactical reticle that the SFP dot sits within is then used for accurate range finding and compensation work where hold overs for moving targets are needed and thanks to the FFP nature this can be used on all magnfications.
These combined features help provide one of the most advanced multipurpose Close Combat and mid-range riflescope designs currently available on the commercial market.
This is the most technically advanced riflescope since the 1-8x24 PM II ShortDot Dual CC combines – in an 8x zoom ratio system – is a distinct illuminated red dot in Second Focal Plane with a First Focal Plane tactical reticle.
This being said, it can be used as a red dot sight for quick engagement of close targets while the MilDot base reticle can be used for accurate ranging and compensation for hold-offs and hold-under/over. The generous eye box/exit pupil supports fast acquisition on any magnification. These combined features create the most advanced multipurpose Close Combat and mid-range riflescope design.
| Length (mm): | 293 |
| Weight (g): | 635 - 650 |
| Field of view m/100 m: | 35.3 - 4.9 |
| Exit pupil mm: | 9.8 - 3.0 |
| Eye relief distance mm: | 90 |
| Twilight factor: | 3.3 - 13.9 |
| Optical data dptr.: | -3/+2 |
| Parallax adjustment: | 100 m fix (7 m in CC-Mode) |
| Colours: | Black, RAL8000 |
| Reticles: | MDR (FFP), MDR-T6 (FFP) combined with red dot in the Second Focal Plane |
| Click value | Adjustment Elevation | Adjustment Windage | Direction | Elevation | Windage |
| 1 cm: | 120 cm / 100 m | ± 60 cm / 100 m | cw | ST MTC LT | ST ZC LT |
| 1 cm: | 120 cm / 100 m | ± 60 cm / 100 m | ccw | ST MTC LT | ST ZC LT |
MDR (FFP) Reticle:
Schmidt & Bender 1-8x24 PM II ShortDot Dual CC MDR 1cm cw ST MTC LT / ST ZC LT Rifle Scope.
