Schmidt & Bender PM II 5-45x56 High Power FFP P4F MTC/LT/DT/ST/CT CCW 0.1 MRAD Zero Stop Rifle Scope
Details
Brand new to the High Power series is the Schmidt & Bender 5-45x56 PM II High Power.
The new Schmidt & Bender 5-45x56 PM II High Power telescopic sight has 9-fold zoom and an upper magnification of 45x making it the perfect telescopic sight for the ultra-long-range marksman.
The ultra flat elevation turret of the Schmidt & Bender 5-45x56 PM II High Power allows the use of a red dot sight for close quarter engagement.
The Schmidt & Bender 5-45x56 offers maximum optical brilliance for perfect target recognition at the longest distances.
The development history of the Schmidt & Bender High Power line is almost as unusual as the riflescopes themselves. When the USSOCOM was looking for a new riflescope for shooting at extreme distances, the Schmidt & Bender 5-45x56 High Power provided the perfect solution - they wanted a 9x zoom and they got a 9x zoom. The Schmidt & Bender 5-45x56 PM II High Power is the latest addition to the High Power line. Apart from the unusual magnification range, the ultra-slim and functional turrets are the main feature of this giant among long range riflescopes.
| Brand | Schmidt & Bender |
|---|---|
| Product Name A-Z | Schmidt & Bender PM II 5-45x56 High Power FFP P4F MTC/LT/DT/ST/CT CCW 0.1 MRAD Zero Stop Rifle Scope |
| SKU | 666-911-972-G8-E8 |
| Highest Magnification | 41x-50x |
| Illuminated Reticle | Yes |
| Minimum Parallax | 30m-∞ |
| Objective Lens Diameter | 56mm |
| Reticle Plane | First |
| Tube Diameter | 34 mm |
| Turret Click Value | 0.1 MRAD (cm) |
Specs
| Unit | A | B | C | D | E | F | G | H | I | J | K | L | M |
| mm inch | 100,42 3,954 | 29,66 1,168 | 57,34 2,258 | 49,75 1,959 | 197,09 7,759 | 62 2,441 | 34 1,339 | 23 0,906 | 23,93 0,942 | 23,93 0,942 | 47,20 1,858 | 434 17,09 | 22,38 0,881 |
| Weight (g) | 1106 |
| Length (mm) | 434 |
| Tube diameter (mm) | 34 |
| Magnification | 5.0-45.0x |
| Objective lens diameter (mm) | 56 |
| Field of view (m) | 7.8 - 0.9 |
| Exit pupil (mm) | 8.8 - 1.2 |
| Eye relief distance (mm) | 90 |
| Twilight factor | 16.7 - 50.2 |
| Transmission | 90 |
| Focal plane | 1. |
| Diopter | -3 to +2 |
| Adjustment | DT MTC LT / ST CT |
| Adjustment value / Click | 1cm |
| Elevation (Turret) | 270 cm/100m 66 MOA/100m |
| Windage (Turret) | ± 60 cm /100m ± 15 MOA/100m |
| Parallax adjustment | 30 m - Infinity |
| Illumination | yes |
| Waterproof (mbar) | 300 |
| Temperature range | |
| Storage | -55 to 70 |
| Function | -40 to 60 |
| Turret Types | ccw |
| Colors | Black |
| Reticles | P4LF |
Reticle
Reticle : P4FL
Warranty
10 Year UK Warranty.
